Camara de Vigilancia IP Dlink DCS-5020L, Inálambrica, Día y Noche 3 años de garantía

Camera

Camera hardware profile

• 1/5” VGA progressive CMOS sensor
• 8 metres IR illumination distance
• Minimum illumination: 0 lux with IR LEDs on
• Built-in Infrared-Cut Removable (ICR) Filter module
• 4X digital zoom
• Lens: fixed length 2.2 mm
• Aperture: F2.0
• Angle of view:
  • (H) 66.22°
  • (V) 49.08°
  • (D) 77.04°
• Exposure time: 1/15 to 1/15,000 sec.
• Built-in microphone



Image features

• Configurable image size, quality, frame rate, and bit rate
• Time stamp and text overlays
• Configurable motion detection windows
• Adjustable brightness, saturation, contrast



Video compression

• Simultaneous H.264/MJPEG format compression
• JPEG for still images



Video resolution

• 640 x 480, 320 x 240, 160 x 112 at frame rates up to 30 fps



Audio compression

• PCM



Connectivity

• 10/100 BASE-TX Ethernet port
• 802.11n wireless



Pan/ Tilt

Pan range

• -170° to +170° (total 340°)



Tilt range

• -25° to +95° (total 120°)



Angular velocity

• 16° per second



Step setting

• Pan 1°/2°/3°/4°/5°(default)/10°/15°/20°/25°/30° per click
• Tilt: 1°/2°/3°/4°/5°(default)/10°/15°/20°/25°/30° per click



Network Network protocols

• IPv4, ARP, TCP, UDP, ICMP
• DHCP client
• NTP client (D-Link)
• DNS client
• DDNS client (D-Link)
• SMTP client
• FTP client
• HTTP server
• PPPoE
• UPnP port forwarding
• LLTD



Security

• Password authentication
• HTTP digest encryption



Advanced Features

System requirements for Web interfaces

• Operating system: Microsoft Windows, XP/Vista/7/8
• Browser: Internet Explorer 7/Firefox 12/Safari 4/Chrome 20 or higher with Java enabled



Event management

• Motion detection
• Sound level detection
• Event notification and uploading of snapshots/video clips via e-mail (SMTP) or FTP



Remote Access

Remote management

• Configuration accessible via web browser



Mobile support

• mydlink Lite app for iOS and Android
• mydlink+ app for iOS and Android



D-ViewCam™ system requirements

• Operating System: Microsoft Windows XP/Vista/7
• Web Browser: Internet Explorer 7 or higher
• Protocol: Standard TCP/IP



D-ViewCam™ software functions

• Remote management/control of up to 32 cameras
• Viewing of up to 32 cameras on one screen
• Supports all management functions provided in web interface
• Scheduled motion triggered, or manual recording options

General

Weight

• Device: 292.4 grams (0.64 lbs)
• Stand: 60.8 grams (0.13 lbs)

Power

• 12 V DC 1 A, 50/60 Hz

Power consumption

• 8.64 watts

Temperature

• Operating: 0 to 40 °C (32 to 104 °F)
• Storage: -25 to 70˚ C (-13 to 158 ˚F)

Humidity

• Operating: 20% to 85% non-condensing
• Storage: 5% to 95% non-condensing

Certifications

• CE
• CE LVD
• FCC
• C-Tick

Dimensions

• 102.35 x 101.27 x 133.6 mm (4.03 x 3.99 x 5.26 inches) (camera only)
• 102.35 x 101.27 x 230.0 mm (4.03 x 3.99 x 9.06 inches) (including mounting bracket)
