Grabador de Video en Red NVR Samsung, 16 Canales, PoE, HDMI/VGA

Ficha técnica

GENERAL

The SRN-1673S 16-Channel Network Video Recorder with PoE Switch (1TB) from Samsung is a plug & play NVR with a built-in PoE/PoE+ network switch that allows cameras to be connected directly to the NVR, eliminating the need for additional hardware. The NVR is equipped with 4 front-accessible SATA ports supporting up to a 6TB HDD each for up to a 24TB total, allowing long-term recording. 1TB come pre-installed.

Up to 16-channel 8M supported

80 Mb/s network camera recording

Plug & play by 16 PoE/PoE+ ports

Removable HDD allows easy installation

HDMI / VGA local monitor

En la Caja

Samsung 16-Channel NVR with PoE Switch (1TB)

Limited 3-Year Warranty

ESPECIFICACIONES

Video
Inputs	16 x RJ45
Resolution	CIF to 8 MP
Protocols	Samsung, ONVIF

Live View
Local Display	HDMI / VGA
Multi-Screen Display	Local monitor: 1 / 4 / 6 / 8 / 9 / 13 / 16 / Auto sequence Web: 1 / 4 / 9 / 16 / Auto sequence
Frame Rate	Local monitor 8 MP (20 fps), 5 MP (30 fps), 3 MP (50 fps), 2 MP (150 fps), 720p (240 fps), D1 (480 fps) Web 5 MP (30 fps), 3 MP (60 fps), 2 MP (120 fps), 720p (240 fps), D1 (480 fps)

Performance
Operating System	Embedded Linux

Recording
Compression	H.264, MJPEG
Bandwidth	80 Mb/s (2 MP 16 camera real-time recording)
Mode	Normal, Scheduled, Event (Pre / Post)
Event Trigger	8 x Alarm input, Video loss, Camera event (Alarm in, MD, Video analytics)
Event Action	E-mail, PTZ preset, Alarm out, Buzzer, Monitor out

Search & Playback
Bandwidth	32 Mb/s
Users	Maximum: 3
Mode	Date & time (calendar) / Event log list / Text Search (POS)
Max Simultaneous Playback	Local Monitor: Up to 16 channels Web, CMS: Up to 16 channels
Resolution	CIF to 8 MP
Fisheye Dewarp Mode	Via Smartviewer
Playback Control	Fast/Slow, Forward/Backward, Move one step up/down

Storage
Storage	1 TB HDD included (pre-installed) 24 TB HDD capacity 4 x internal SATA supporting up to 6 TB HDD each 1 x external e-SATA

Backup
File Format	USB: BU/Exe Web, CMS: JPEG, AVI
Function	Maximum 16 channel playback, Date-time/title display

Sensor
Input / Output	8 / 4 (3 x NO, 1 x NO/NC)

Audio
Input	8-channel (Network)
Compression	G.711, G.726, AAC (16 / 48 kHz)
Audio Communication	2-way

Network
Protocol Support	TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S)
DDNS	Samsung iPOLiS DDNS
Bandwidth	Maximum 160 Mb/s (transmission)
Max. Remote Users	Search: 3 Live Unicast: 10 Live Multicast: 20
IP	IPv4 / IPv6
Security	IP address filtering, User access log, 802.1x authentication, Encryption
GUI/Setup Menu Language	English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai
OS	Windows: XP SP2 and above, Vista, 7, 8, Mac OS: OSX 10.6 and above
Web Browser	Internet Explorer: Updated Version 8 to 10 (9 or above recommended) Firefox: Version 19.x and above Chrome: Version 26.x and above Apple Safari: Version 6.0.3 and above
Viewer	SSM, Webviewer, SmartViewer, iPOLiS mobile viewer CMS Support: SDK / CGI (SUNAPI)

Setup and Configuration
Registration	PnP mode, Manual mode
Functions	IP address, Add Profile Edit, Bitrate, Compression, GOP, Quality, Camera MD setup, Camera video setup (Simple focus, Brightness / Contrast, Flip / Mirror, Iris, WDR, D&N, SSNR, Shutter, SSDR, DIS)
Camera Control	PoE: Monitor PoE power consumption, On / Off control for each PoE camera, Remote reset for each PoE camera
Configuration	Setup Wizard (Date / Time, Network, Auto camera configuration)

PTZ
Control	Via GUI, Webviewer, SPC-2000
Presets	255

Smartphone
OS Support	Android, iOS
Control	Live: 4 Playback: 1
System Control	Mouse, IR Remocon, Web, SPC-2000 (Controller)

Indicators
Front Panel Indicators	1 x Power status LED, 1 x HDD action LED, 1 x Alarm status LED, 1 x Record status LED, 1 x Network action LED, 1 x Back up LED

Interfaces / Ports
USB	2 (Front panel)
Display	1 x HDMI / VGA
Audio Out	1 x RCA, line
Network	8 x RJ45 (PoE/PoE+, 100 Mb/s) 1 x RJ45 (WAN, 1 Gb/s)
Alarm I/O	8 x Alarm in (terminal block) 4 x Alarm out (terminal block)
Reset	Factory reset

System
Log Entries	System Log: Maximum 20,000 Event Log: Maximum 20,000

Electrical
Input Voltage/Current	100 to 240 VAC / 6 to 3 A, 50/60 Hz
Power Consumption	Maximum 309 W (4 HDD, PoE on), 57 W (2 HDD, PoE off)
PoE Budget	Maximum: 200 W

Environmental
Operating Temperature	32 to 104°F (0 to 40°C)
Operating Humidity	20 to 85% RH

Mechanical
Material	Metal
Dimensions (W x H x D)	17 x 3.5 x 15" (44 x 8.8 x 39 cm) (2U)
Weight	Approximately 12.3 lb (5.60 kg), including 1 x 1 TB HDD

Packaging Info
Package Weight	17.15 lb
Box Dimensions (LxWxH)	21.181 x 19.528 x 7.244"

Precios y disponibilidad sujetos a cambio sin previo aviso. Las imágenes pueden no corresponder al producto y sólo se muestran con fines ilustrativos. Para envíos gratis, aplican restricciones.

Grabador de Video en Red NVR Samsung, 16 Canales, PoE, HDMI/VGA 3 años de garantía

Número de Parte: SRN-1673S-1TB
