| 5000-lumen Entry-Level Professional Installation Projector |
| MODEL: NP-P501X |
Maximize your brightness during presentations with the NEC P501X, an entry-level professional installation projector loaded with eco-friendly and advanced technologies. Ideal for corporate boardrooms, higher education classrooms and government training rooms, this model delivers remarkable brightness (5000 lumens) and features built-in wall color correction, wired and optional wireless networking, closed captioning and up to 6000 hours of lamp life (in ECO Mode™). The P501X touts an active lens cover, which hides content, mutes audio and lowers lamp brightness to 25%, allowing you to maximize the effectiveness of your presentations.
|
| Optical |
|
|
|
|
| Display Technology | 0.63" LCD w/ MLA | |
| Light Output(Lumens) | 5000 normal / Eco = approx. 60% of normal mode | |
| Resolution | | Native | XGA 1024 x 768 | |
| Maximum | UXGA 1600 x 1200 | |
| |
| | Contrast Ratio (up to) | 4000:1 | |
| Lamp Type | 270W AC / 160W eco | |
| Lamp Life (up to) | 3500 hours normal /6000 hours eco | |
| Screen Size (diagonal) | 25 to 300 in. / 0.64 to 7.6m | |
| Throw Ratio | 1.3 to 2.2 | |
| Projection Distance | 1.9 to 45.3 ft. / 0.6 to 13.8m | |
| Projector Angle | 0 to 9.8° tele / 0 to 16.5° wide | |
| Lens | | Zoom | 1.7 | |
| Focus | Manual | |
| F number, fnumber | F=1.7 to 2.1, f=17.4 to 29mm | |
| |
| | Keystone Correction | Manual +/- 30° | |
|
|
|
| Signal Compatibility/Connectivity |
|
|
|
|
| Scan Rate | | Horizontal | 15-100 kHz | |
| Vertical | 50-120 Hz | |
| |
| | Supported Video Standards | NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM | |
| SD/HD Video Signal Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, Y/Cb/Cr component (with optional adapter – ADP-CV1E) | |
| PC Signal Compatibility | VGA, SVGA, XGA, SXGA, SXGA+, UXGA | |
| Macintosh Compatibility | Yes | |
| Input/Output Terminals | | RGB1(analog) | VGA 15-pin D-sub | |
| RGB3(digital) | HDMI w/ HDCP | |
| RGB4(digital) | USB A type | |
| Video 1 | RCA | |
| Video 2 | S-Video | |
| Audio 1 | L/R RCA (shared by video sources) | |
| Audio 2 | 1/8 in. stereo | |
| Audio 3 | 1/8 in. stereo | |
| Monitor out | VGA 15-pin D-sub | |
| Audio out | Yes (variable) | |
| |
| | Audio | 16W speaker | |
| External Control | RS-232, IR, Wired LAN, DDC/CI, USB, Wireless LAN | |
| Sync Compatiblity | Separate Sync / Composite Sync / Sync on G | |
| Networking | RJ-45 Monitoring | |
|
|
|
| Electrical |
|
|
|
|
| Power Requirements | 100-240V AC, 50/60 Hz | |
| Input Current | 4.2A/1.7A | |
| Power Consumption (Normal/ECO Mode/Standby/Standby Power Saving) | 357W / 231W / 10W / 0.2W | |
|
|
|
| Mechanical |
|
|
|
|
| Installation Orientation | Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear | |
| Dimensions (WxDxH) | 15.7 x 11.1 x 4.5 in. / 398 x 282 x 115mm | |
| Net Weight | 9 lbs. / 4.1 kg | |
| Fan Noise | 37 dB normal / 30 dB eco | |
| Regulations | UL60950-1, CSA60950-1, FCC Part 15 Class B, ICES-03 Class B, NOM-001-SCFI-1993 | |
|
|
|
| Environmental |
|
|
|
|
| Operating Temperature | 41-104°F / 5-40°C | |
| Humidity | 20-80% non-condensing | |
| Storage | -14-122°F / -10-50°C | |
|
|
|
| Limited Warranty |
|
|
|
| 3 years. First year Instacare Service. Lamp warranty is 1 year or 500 hours, whichever comes first. |
|
|
| Additional Features |
|
|
|
- Wireless LAN
- Active Lens Cover
- USB Viewer
- Cornerstone
- Geometric Correction
- Auto power on
- ECO Mode technology
- Closed captioning
- Variable audio out
- Carbon savings meter
- Virtual Remote
- Sleep timer
- Quick power-off
- Built-in wall color correction
- Advanced Acc
|
